| Method / sample set | ΔH | ΔS estimate |
|---|---|---|
| uMLIP (PBE sample set) |
0.217442 ± 0.0126 eV/atom
20.9799 ± 1.22 kJ/mol of atoms
|
0.000124279 ± 7.64e-06
eV/(atom K)
11.9911 ± 0.737 J/(mol of atoms K)
|
| PBE |
0.211821 ± 0.0111 eV/atom
20.4376 ± 1.07 kJ/mol of atoms
|
Inherited from matched uMLIP estimate
11.9911 ± 0.737 J/(mol of atoms K)
|
| uMLIP (R2SCAN sample set) |
0.217442 ± 0.0126 eV/atom
20.9799 ± 1.22 kJ/mol of atoms
|
0.000124279 ± 7.64e-06
eV/(atom K)
11.9911 ± 0.737 J/(mol of atoms K)
|
| R2SCAN |
0.234472 ± 0.0146 eV/atom
22.6231 ± 1.41 kJ/mol of atoms
|
Inherited from matched uMLIP estimate
11.9911 ± 0.737 J/(mol of atoms K)
|
ΔH is the liquid-minus-solid value reported by the existing correction workflow. Each uMLIP row uses the sample set matched to that DFT method. Uncertainties are standard errors; — means unavailable.
ΔS is estimated as ΔHuMLIP/Tm,uMLIP. Its propagated uncertainty assumes these two quantities are independent. The current PBE/R2SCAN correction inherits this entropy estimate; it is not an independently calculated DFT entropy.
| Sample set | Cp,solid | Cp,liquid |
|---|---|---|
| uMLIP (PBE sample set) |
28.8455 J/(mol of atoms K)
0.000298962 eV/(atom K)
|
26.1043 J/(mol of atoms K)
0.000270552 eV/(atom K)
|
| uMLIP (R2SCAN sample set) |
28.8455 J/(mol of atoms K)
0.000298962 eV/(atom K)
|
26.1043 J/(mol of atoms K)
0.000270552 eV/(atom K)
|
Values reported in SLUSCHI.out by the correction workflow. These are uMLIP potential-energy–temperature slopes for the PBE/R2SCAN sample sets, not full thermodynamic heat capacities or independent DFT heat capacities. The workflow may substitute the other phase's slope when one is unavailable. Uncertainties are not reported; — means unavailable.
| Vsolid [ų/atom] | Vliquid [ų/atom] | ΔV [ų/atom] |
|---|---|---|
| 12.3904 ± 0.094 | 13.0455 ± 0.0756 | 0.65505 ± 0.108 |
=======================================================================================================
Solid and Liquid in Ultra Small Coexistence with Hovering Interfaces (SLUSCHI)
Developed and maintained by Qi-Jun Hong, with early research support from Axel van de Walle (2014-2020)
=======================================================================================================
Generating solid with radius = 11
*** Generate a supercell from the current unitcell ***
The supercell is:
0.0000000000000000 0.0000000000000000 -10.569342870000000
0.0000000000000000 10.569345869999999 0.0000000000000000
10.568803800000001 0.0000000000000000 0.0000000000000000
|a|,|b|,|c|,theta(bc),theta(ac),theta(ab):
10.569 10.569 10.569 90.000 90.000 90.000
In UNIT-cell, number of atoms: 1 3 total: 4
Inverse Matrix is:
0.0000000000000000 -0.0000000000000000 9.4618087242758733E-002
0.0000000000000000 9.4613234565291054E-002 -0.0000000000000000
-9.4613261420291125E-002 0.0000000000000000 0.0000000000000000
In SUPER-cell, number of atoms: 27 81 total: 108
POSCAR_STRCT atoms = 108
Accepted radius = 11 with 108 atoms
====================================================================================================
=== SLUSCHI fit-first-1-guard1; source: /u/hqj/sluschi-up/src ===
/projects/bhin/hqj/sluschi_auto/7adaadd7-523b-4f23-9a26-026c1fdc828e/AlNi3/Dir_lammps
['Al', 'Ni']
elements: ['Al', 'Ni']
counts: [27, 81]
solid atom IDs: 1:108
liquid atom IDs: 109:216
Original Tm = 1000.0
New temp = 500
New temp_end = 2000
500, 2000, 1
Adaptive temp step = 500
500 K: 0/1 usable completed; 0 genuinely resolved; no replacement attempts
Starting NEW trajectory 500/1, step_param=1000
Pressure trial 1: scale=1.0
Pressure = 17288.1494
Pressure trial 2: scale=1.01
Pressure = -26071.8734
Pressure trial 3: scale=1.0050000000000001
Pressure = -5279.27449
Pressure trial 4: scale=1.0000000000000002
Pressure = 17288.1498
Pressure trial 5: scale=1.0025000000000002
Pressure = 5843.98157
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: solid
500 K: 1/1 usable completed; 1 genuinely resolved; no replacement attempts
1000 K: 0/1 usable completed; 0 genuinely resolved; no replacement attempts
Starting NEW trajectory 1000/1, step_param=1000
Pressure trial 1: scale=1.0025000000000002
Pressure = 60141.2783
Pressure trial 2: scale=1.0125000000000002
Pressure = 12332.95366
Pressure trial 3: scale=1.0225000000000002
Pressure = -22837.4634
Pressure trial 4: scale=1.0175000000000003
Pressure = -7389.22044
Pressure trial 5: scale=1.0125000000000004
Pressure = 12329.37931
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: solid
1000 K: 1/1 usable completed; 1 genuinely resolved; no replacement attempts
1500 K: 0/1 usable completed; 0 genuinely resolved; no replacement attempts
Starting NEW trajectory 1500/1, step_param=1000
Pressure trial 1: scale=1.0125000000000004
Pressure = 61564.9786
Pressure trial 2: scale=1.0225000000000004
Pressure = 24168.9932
Pressure trial 3: scale=1.0325000000000004
Pressure = -9827.401682
Pressure trial 4: scale=1.0275000000000005
Pressure = 9122.64843
Pressure trial 5: scale=1.0300000000000005
Pressure = 1626.053515
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: solid
1500 K: 1/1 usable completed; 1 genuinely resolved; no replacement attempts
2000 K: 0/1 usable completed; 0 genuinely resolved; no replacement attempts
Starting NEW trajectory 2000/1, step_param=1000
Pressure trial 1: scale=1.0300000000000005
Pressure = 42627.3891
Pressure trial 2: scale=1.0400000000000005
Pressure = 9923.73306
Pressure trial 3: scale=1.0500000000000005
Pressure = -18592.96068
Pressure trial 4: scale=1.0450000000000006
Pressure = -2483.00512
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: liquid
2000 K: 1/1 usable completed; 1 genuinely resolved; no replacement attempts
Initial scan stopped at 2000 K: confirmed liquid. Fitting before further MD.
Wrote summary.csv and summary.out for 4 trajectories
Wrote phase_pred.csv: {'solid': 3, 'liquid': 1}
Wrote jobs_results.out (weighted counts); 0 unresolved trajectories
FIT NOW: reporting the partial batch before further MD.
=== running MPFit ===
Melting temperature and std error: 1514.7393730000001 7265.0339319591594
500 1 0 1
1000 1 0 1
1500 1 0 1
2000 0 1 1
=== Find next job to run ===
next job: 1 MD duplicate(s) at 1750.0000000000000 K
1750, 1750, 1
Adaptive temp step = 100
1750 K: 0/1 usable completed; 0 genuinely resolved; no replacement attempts
Starting NEW trajectory 1750/1, step_param=1000
Pressure trial 1: scale=1.0450000000000006
Pressure = -17549.58607
Pressure trial 2: scale=1.0400000000000007
Pressure = -7165.23121
Pressure trial 3: scale=1.0350000000000008
Pressure = 7893.558627
Pressure trial 4: scale=1.0375000000000008
Pressure = 4733.5915
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: solid
1750 K: 1/1 usable completed; 1 genuinely resolved; no replacement attempts
Wrote summary.csv and summary.out for 5 trajectories
Wrote phase_pred.csv: {'solid': 4, 'liquid': 1}
Wrote jobs_results.out (weighted counts); 0 unresolved trajectories
=== running MPFit ===
Melting temperature and std error: 1771.8571099999999 6969.6874827133352
500 1 0 1
1000 1 0 1
1500 1 0 1
1750 1 0 1
2000 0 1 1
=== Find next job to run ===
next job: 1 MD duplicate(s) at 1875.0000000000000 K
1875, 1875, 1
Adaptive temp step = 100
1875 K: 0/1 usable completed; 0 genuinely resolved; no replacement attempts
Starting NEW trajectory 1875/1, step_param=1000
Pressure trial 1: scale=1.0450000000000006
Pressure = -11120.892524
Pressure trial 2: scale=1.0400000000000007
Pressure = 270.72838
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: liquid
1875 K: 1/1 usable completed; 1 genuinely resolved; no replacement attempts
Wrote summary.csv and summary.out for 6 trajectories
Wrote phase_pred.csv: {'solid': 4, 'liquid': 2}
Wrote jobs_results.out (weighted counts); 0 unresolved trajectories
=== running MPFit ===
Melting temperature and std error: 1793.5516874999998 6978.0700996709320
500 1 0 1
1000 1 0 1
1500 1 0 1
1750 1 0 1
1875 0 1 1
2000 0 1 1
=== Find next job to run ===
next job: 4 MD duplicate(s) at 1750.0000000000000 K
next job: 4 MD duplicate(s) at 1875.0000000000000 K
1750, 1750, 4
Adaptive temp step = 100
1750 K: 1/4 usable completed; 1 genuinely resolved; no replacement attempts
Starting NEW trajectory 1750/2, step_param=1100
Pressure trial 1: scale=1.0375000000000008
Pressure = 2361.210988
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: liquid
1750 K: 2/4 usable completed; 2 genuinely resolved; no replacement attempts
Starting NEW trajectory 1750/3, step_param=1200
Pressure trial 1: scale=1.0375000000000008
Pressure = -2235.69958
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: liquid
1750 K: 3/4 usable completed; 3 genuinely resolved; no replacement attempts
Starting NEW trajectory 1750/4, step_param=1300
Pressure trial 1: scale=1.0375000000000008
Pressure = 1560.002771
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: solid
1750 K: 4/4 usable completed; 4 genuinely resolved; no replacement attempts
1875, 1875, 4
Adaptive temp step = 100
1875 K: 1/4 usable completed; 1 genuinely resolved; no replacement attempts
Starting NEW trajectory 1875/2, step_param=1100
Pressure trial 1: scale=1.0400000000000007
Pressure = 2768.39451
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: liquid
1875 K: 2/4 usable completed; 2 genuinely resolved; no replacement attempts
Starting NEW trajectory 1875/3, step_param=1200
Pressure trial 1: scale=1.0400000000000007
Pressure = 1330.45345
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: liquid
1875 K: 3/4 usable completed; 3 genuinely resolved; no replacement attempts
Starting NEW trajectory 1875/4, step_param=1300
Pressure trial 1: scale=1.0400000000000007
Pressure = 6012.130683
Pressure trial 2: scale=1.0500000000000007
Pressure = -24520.77361
Pressure trial 3: scale=1.0450000000000008
Pressure = -12346.42888
Pressure trial 4: scale=1.040000000000001
Pressure = 1700.28774
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: liquid
1875 K: 4/4 usable completed; 4 genuinely resolved; no replacement attempts
Wrote summary.csv and summary.out for 12 trajectories
Wrote phase_pred.csv: {'solid': 5, 'liquid': 7}
Wrote jobs_results.out (weighted counts); 0 unresolved trajectories
=== running MPFit ===
Melting temperature and std error: 1665.7007679968744 292.06337731887322
500 1 0 1
1000 1 0 1
1500 1 0 1
1750 2 2 4
1875 0 4 4
2000 0 1 1
=== Find next job to run ===
next job: 1 MD duplicate(s) at 1625.0000000000000 K
next job: 1 MD duplicate(s) at 1625.0000000000000 K
1625, 1625, 1
Adaptive temp step = 100
1625 K: 0/1 usable completed; 0 genuinely resolved; no replacement attempts
Starting NEW trajectory 1625/1, step_param=1000
Pressure trial 1: scale=1.0375000000000008
Pressure = -2508.535342
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: solid
1625 K: 1/1 usable completed; 1 genuinely resolved; no replacement attempts
1625, 1625, 1
Adaptive temp step = 100
1625 K: 1/1 usable completed; 1 genuinely resolved; no replacement attempts
Wrote summary.csv and summary.out for 13 trajectories
Wrote phase_pred.csv: {'solid': 6, 'liquid': 7}
Wrote jobs_results.out (weighted counts); 0 unresolved trajectories
=== running MPFit ===
Melting temperature and std error: 1713.0069726655213 122.72147078847571
500 1 0 1
1000 1 0 1
1500 1 0 1
1625 1 0 1
1750 2 2 4
1875 0 4 4
2000 0 1 1
=== Find next job to run ===
next job: 4 MD duplicate(s) at 1625.0000000000000 K
next job: 4 MD duplicate(s) at 1625.0000000000000 K
1625, 1625, 4
Adaptive temp step = 100
1625 K: 1/4 usable completed; 1 genuinely resolved; no replacement attempts
Starting NEW trajectory 1625/2, step_param=1100
Pressure trial 1: scale=1.0375000000000008
Pressure = -6241.682186
Pressure trial 2: scale=1.0325000000000009
Pressure = 14662.45067
Pressure trial 3: scale=1.0350000000000008
Pressure = -3701.44984
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: solid
1625 K: 2/4 usable completed; 2 genuinely resolved; no replacement attempts
Starting NEW trajectory 1625/3, step_param=1200
Pressure trial 1: scale=1.0350000000000008
Pressure = 650.001125
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: solid
1625 K: 3/4 usable completed; 3 genuinely resolved; no replacement attempts
Starting NEW trajectory 1625/4, step_param=1300
Pressure trial 1: scale=1.0350000000000008
Pressure = 3582.678083
Production: at most 8 blocks of 10000 steps, including the first
Completed! Phase: solid
1625 K: 4/4 usable completed; 4 genuinely resolved; no replacement attempts
1625, 1625, 4
Adaptive temp step = 100
1625 K: 4/4 usable completed; 4 genuinely resolved; no replacement attempts
Wrote summary.csv and summary.out for 16 trajectories
Wrote phase_pred.csv: {'solid': 9, 'liquid': 7}
Wrote jobs_results.out (weighted counts); 0 unresolved trajectories
=== running MPFit ===
Melting temperature and std error: 1749.6251443063695 35.759029896072008
500 1 0 1
1000 1 0 1
1500 1 0 1
1625 4 0 4
1750 2 2 4
1875 0 4 4
2000 0 1 1
current fit
1 1749.6251443063695 35.759029896072008
possibilities:
current fit
0 1749.6251443063695 35.759029896072008
possibilities:
MP accuracy achieved. Stopping code...
summary.out
======================================================================================================================================================
folder poteng [eV/atom] kineng [eV/atom] temp [K] volume [Ang^3/atom] press [bar] energy_slope energy_dir diffusion [cm^2/s] spg phase left_phase right_phase left_D [cm^2/s] right_D [cm^2/s] phase_reason last_md_step phase_check
1000/1 -5.551777 0.127423 990.375226 11.797748 1985.130652 0.00000045 up 0.00000000e+00 solid solid solid 0.00000000e+00 0.00000000e+00 Both original halves agree 11100 RESOLVED
1500/1 -5.465784 0.192564 1496.670250 11.990646 16518.200415 -0.00000438 down 0.00000000e+00 solid solid solid 0.00000000e+00 2.95761894e-08 Both original halves agree 11100 RESOLVED
1625/1 -5.432866 0.210385 1635.180215 12.083916 18273.895600 -0.00000906 down 0.00000000e+00 solid solid solid 0.00000000e+00 0.00000000e+00 Both original halves agree 11100 RESOLVED
1625/2 -5.422879 0.211483 1643.715455 12.190509 9398.795925 -0.00001379 down 0.00000000e+00 solid solid solid 0.00000000e+00 0.00000000e+00 Both original halves agree 11200 RESOLVED
1625/3 -5.428716 0.212344 1650.404445 12.147463 11839.705063 -0.00001237 down 4.53735207e-08 solid solid solid 0.00000000e+00 0.00000000e+00 Both original halves agree 11300 RESOLVED
1625/4 -5.375879 0.211681 1645.251945 12.601974 -19327.467735 -0.00001184 down 0.00000000e+00 solid solid solid 0.00000000e+00 0.00000000e+00 Both original halves agree 11400 RESOLVED
1750/1 -5.366829 0.227322 1766.822515 12.696537 -22859.293850 -0.00001612 down 0.00000000e+00 solid solid solid 0.00000000e+00 0.00000000e+00 Both original halves agree 11100 RESOLVED
1750/2 -5.230294 0.222423 1728.743650 12.916418 11948.079770 0.00000306 up 2.05466895e-05 liquid liquid liquid 1.10870569e-05 3.00063221e-05 Both original halves agree 31200 RESOLVED
1750/3 -5.214618 0.223275 1735.361095 13.123626 -2567.404053 0.00000105 up 2.19237885e-05 liquid liquid liquid 2.44909568e-05 1.93566201e-05 Both original halves agree 61300 RESOLVED
1750/4 -5.380328 0.226361 1759.349830 12.423918 -1741.003316 -0.00000979 down 0.00000000e+00 solid solid solid 0.00000000e+00 0.00000000e+00 Both original halves agree 11400 RESOLVED
1875/1 -5.179309 0.243784 1894.768235 13.323211 -6574.265618 0.00000610 up 3.97579972e-05 liquid liquid liquid 3.42619436e-05 3.62202778e-05 Both original halves agree 21100 RESOLVED
1875/2 -5.188258 0.244140 1897.531045 13.255681 -4643.460232 0.00000921 up 4.67987037e-05 liquid liquid liquid 4.73227815e-05 3.90600704e-05 Both original halves agree 11200 RESOLVED
1875/3 -5.196213 0.244316 1898.904780 13.233540 -6911.042250 0.00000798 up 2.91346523e-05 liquid liquid liquid 2.50605199e-05 3.32087846e-05 Both original halves agree 11300 RESOLVED
1875/4 -5.181916 0.238335 1852.416575 13.250470 -1763.189023 0.00001202 up 3.64292788e-05 liquid liquid liquid 3.43688479e-05 3.84897096e-05 Both original halves agree 11400 RESOLVED
2000/1 -5.156442 0.254267 1976.244925 13.381237 -2762.336667 0.00000726 up 6.63359165e-05 liquid liquid liquid 6.75732177e-05 6.50986153e-05 Both original halves agree 11100 RESOLVED
500/1 -5.635208 0.064544 501.652945 11.547893 -1926.562080 0.00000015 up 0.00000000e+00 solid solid solid 0.00000000e+00 0.00000000e+00 Both original halves agree 11100 RESOLVED
======================================================================================================================================================
Wrote summary.csv and summary.out for 16 trajectories
Wrote phase_pred.csv: {'solid': 9, 'liquid': 7}
Wrote jobs_results.out (weighted counts); 0 unresolved trajectories
Wrote /projects/bhin/hqj/sluschi_auto/7adaadd7-523b-4f23-9a26-026c1fdc828e/AlNi3/Dir_lammps/cost_table.out
Collected 56 log files
====================================
Computational cost summary:
Number of trajectories (temp/id) = 16
Total log files (incl. subruns) = 56
Total wall time = 19:46:31
Total seconds = 71191
Total GPU hours = 19.78
====================================
=== DFT corrections begin ===
=== PBE correction ===
PBE_METHOD = PBE
N rows with PBE energy = 12
MT_LMP = 1749.6251443063695
STD_LMP = 35.75902989607201
SOLID (PBE present only):
lammps_poteng_eV_per_atom = -5.41275170
PBE_energy_eV_per_atom = -5.20864322
N_solid_PBE = 6
SEM_lammps_solid_PBE = 9.28970051e-03 eV/atom
SEM_PBE_solid = 8.31916361e-03 eV/atom
LIQUID (PBE present only):
lammps_poteng_eV_per_atom = -5.19531003
PBE_energy_eV_per_atom = -4.99682217
N_liquid_PBE = 6
SEM_lammps_liquid_PBE = 8.52516151e-03 eV/atom
SEM_PBE_liquid = 7.28981046e-03 eV/atom
DH_LMP_raw_PBE = 0.21744167 eV/atom
DH_LMP_PBE = 0.21744167 eV/atom
DH_PBE = 0.21182105 eV/atom
STD_DH_LMP_PBE = 1.26086048e-02 eV/atom
STD_DH_PBE = 1.10611853e-02 eV/atom
COV_DH_PBE_LMP = 1.38565125e-04 (eV/atom)^2
Cp_solid_PBE = 2.98962037e-04 eV/atom/K
Cp_liquid_PBE = 2.70551852e-04 eV/atom/K
Cp_avg_PBE = 0.00000000e+00 eV/atom/K
DeltaT_PBE = 166.67 K
DH_raw_PBE = 0.21182105 eV/atom
MT_PBE = 1704.39932525 K
STD_PBE = 37.73211502 K
=== R2SCAN correction ===
N rows with R2SCAN energy = 12
MT_LMP = 1749.6251443063695
STD_LMP = 35.75902989607201
SOLID (R2SCAN present only):
lammps_poteng_eV_per_atom = -5.41275170
R2SCAN_energy_eV_per_atom = -10.75189863
N_solid_R2SCAN = 6
SEM_lammps_solid_R2SCAN = 9.28970051e-03 eV/atom
SEM_R2SCAN_solid = 1.16729395e-02 eV/atom
LIQUID (R2SCAN present only):
lammps_poteng_eV_per_atom = -5.19531003
R2SCAN_energy_eV_per_atom = -10.51742703
N_liquid_R2SCAN = 6
SEM_lammps_liquid_R2SCAN = 8.52516151e-03 eV/atom
SEM_R2SCAN_liquid = 8.73203057e-03 eV/atom
DH_LMP_raw_R2SCAN = 0.21744167 eV/atom
DH_LMP_R2SCAN = 0.21744167 eV/atom
DH_R2SCAN = 0.23447160 eV/atom
STD_DH_LMP_R2SCAN = 1.26086048e-02 eV/atom
STD_DH_R2SCAN = 1.45775812e-02 eV/atom
COV_DH_R2SCAN_LMP = 1.80806939e-04 (eV/atom)^2
Cp_solid_R2SCAN = 2.98962037e-04 eV/atom/K
Cp_liquid_R2SCAN = 2.70551852e-04 eV/atom/K
Cp_avg_R2SCAN = 0.00000000e+00 eV/atom/K
DeltaT_R2SCAN = 166.67 K
DH_raw_R2SCAN = 0.23447160 eV/atom
MT_R2SCAN = 1886.65495695 K
STD_R2SCAN = 44.35711101 K
=== DFT corrections end ===
Al1 Ni3 1.0 3.5229346000000001 0.0000000000000000 -0.0000000000000000 0.0000000000000000 3.5231152899999998 0.0000000000000000 0.0000000000000000 0.0000000000000000 3.5231142900000001 Al Ni 1 3 direct 0.0000000000000000 -0.0000000000000000 -0.0000000000000000 Al 0.0000000000000000 0.5000000000000000 0.5000000000000000 Ni 0.5000000000000000 0.0000000000000000 0.5000000000000000 Ni 0.5000000000000000 0.5000000000000000 0.0000000000000000 Ni
No output files have been received yet.
